Two-Lane Flow Weigher for Free-Flowing Products
Two-Lane Flow Weigher is a gravimetric dosing unit designed for accurate weighing of free-flowing, granular, small-piece and selected abrasive products in two product streams.
The weigher is suitable for grains, cereals, pasta, sugar, salt, spices, tea, coffee, cookies, candies, gingerbread, nuts, dried fruits, chips, frozen vegetables, berries, mushrooms, seafood, dumplings, pet food, detergents, granulated fertilizers and other food or non-food products.
The two-lane flow weigher is an economical medium-output solution for manufacturers that need accurate weight dosing in two streams. It provides higher productivity than a single-lane weigher while keeping the system simpler than multihead combination weighing.
The product is fed through vibrating chutes into weighing bins, where each target dose is formed by weight. After the dose is reached, the portion is discharged into a packaging machine, container or receiving system.
The weigher is controlled by a microprocessor weighing terminal, and operating information is shown on the display. For frozen products, product-contact parts can be made of corrugated stainless steel to improve product movement.
The two-lane flow weigher can operate as standalone dosing equipment or be integrated with SIGITASPAK packaging machines and complete packaging lines for manufacturers in the UAE, GCC countries, the Middle East, Africa and other international markets.
| Kinematic speed, max | 40 doses/min |
| Dose weight, min | 0.015 kg |
| Dose weight, max | 2 kg |
| Dosing type | Weighing / gravimetric dosing |
| Dosing accuracy | Meets applicable weighing standards |
| Dosing accuracy for small-piece products | ±1 pc |
| Power supply | 220 V, 1 phase, 50 Hz |
| Installed power | 1.5 kW |
| Air pressure | 0.6 MPa |
| Compressed air consumption | 40 l/min |
| Machine length, max | 1400 mm |
| Machine width, max | 1330 mm |
| Machine height, max | 1115 mm |
| Machine weight, max | 230 kg |
Advantages
- Accurate gravimetric dosing in two product streams
- Higher output than a single-lane flow weigher
- Suitable for fine, medium and small-piece products
- Can dose selected abrasive products
- Dose range from 0.015 to 2 kg
- Output up to 40 doses/min
- Accuracy for small-piece products up to ±1 pc
- Microprocessor weighing terminal with display
- Corrugated stainless steel product-contact parts available for frozen products
- Can operate separately or with packaging machines
- Economical solution for medium-output production lines
Standard accessories
- Weighing bins
- Weighing devices
- Weight measuring units
- Control unit
- Framework with feeding hopper
- Upper and lower vibrating chutes
- Coarse filling brush
- Fine adjustment brush
- Adjustment vibrating chute
- Product level control sensors
- Discharge funnel
Optional equipment
- Corrugated stainless steel product-contact parts for frozen products
- Integration with VFFS packaging machines
- Integration with conveyors and feeding systems
- Special configuration for abrasive products
- Other options on request
- Grains and cereals
- Pasta
- Sugar
- Salt
- Spices
- Tea
- Coffee
- Cookies and biscuits
- Candies
- Gingerbread and spice cakes
- Sushki and dry bakery products
- Crackers and croutons
- Crispbread
- Chips
- Nuts
- Dried fruits
- Frozen vegetables
- Frozen berries
- Frozen mushrooms
- Seafood
- Dumplings and ravioli
- Detergents
- Granulated fertilizers
- Animal feed and pet food
- Cat litter
- Building materials
- Other free-flowing, granular, small-piece and abrasive products suitable for gravimetric dosing
